Description
B&R 4PP065.0571-X74F
Technical Specifications:
- Brand: B&R Industrial Automation
- Model: 4PP065.0571-X74F
- Product Type: Panel PC / HMI with integrated keys
- Display: High-resolution TFT color touchscreen
Functional Features:
- Integrated Operation: Combines visualization, data logging, and physical key operation in a single compact device.
- High-Speed Processing: Powered by robust processors to handle complex visualization and real-time control tasks.
- Industrial Connectivity: Features multiple communication ports (Ethernet, USB) for seamless integration with PLCs and drives.
Application Scenarios:
Widely used as the primary operator interface on packaging machines, textile equipment, and automated manufacturing cells.
Performance Parameters:
- Touch Response: Fast, accurate multi-touch or resistive touch response for precise operator input.
- Brightness: High-brightness display optimized for visibility in varying industrial lighting conditions.
Material Composition:
Front panel constructed from durable, chemical-resistant glass or polycarbonate. Rear housing is made of high-impact, flame-retardant metal or plastic.
Structural Features:
Ergonomic design featuring a combination of a touchscreen and membrane or mechanical function keys for blind operation. Standard cutout dimensions for easy panel integration.
Working Principle:
Runs visualization software (e.g., B&R Automation Studio) to render graphical interfaces, process operator touch/key inputs, and communicate with the underlying PLC via Ethernet or serial protocols.
Installation Requirements:
Mount securely into a standard rectangular panel cutout using the provided mounting brackets. Ensure adequate rear clearance for heat dissipation and cable routing.
Usage Precautions:
Clean the touchscreen only with approved, non-abrasive cleaning agents. Avoid exposing the panel to direct, high-intensity sunlight or excessive mechanical shock.
