Description
Bently 330103-00-07-05-02-00
Technical Specifications
- Product Series: 3300 XL 8mm Eddy Current Sensor System
- Probe Diameter: 8 mm (0.315 inches)
- Sensitivity: 200 mV/mil (7.87 V/mm)
- Thread Specification: M10 x 1 Metric Thread
- System Length: 1.5 meters (5 feet) total system length
Functional Features
- Compact System Footprint: Ideal for OEM installations and retrofit applications with limited space for cable routing.
- Precision Signal Conditioning: Delivers highly accurate displacement and vibration data for advanced diagnostic algorithms.
- Rugged Construction: Engineered to withstand extreme mechanical shock and continuous high-frequency vibration.
Application Scenarios
Perfectly suited for smaller rotating equipment, auxiliary pumps, cooling fans, and gearboxes in steel mills, paper mills, and water treatment facilities.
Performance Parameters
- Linear Measurement Range: 80 mils (2.0 mm)
- Frequency Response: 0 to 10 kHz (-3 dB)
- Operating Temperature Range: -52°C to +177°C (-62°F to +350°F)
- Supply Voltage: -24 VDC nominal
Material Composition
Constructed with premium 316L stainless steel and high-temperature dielectric materials, ensuring structural integrity and electrical isolation in demanding environments.
Structural Characteristics
Features a streamlined profile with an integrated cable exit that minimizes bending stress. The connector is designed for secure mating in high-vibration zones.
Working Principle
Operates on the principle of electromagnetic induction. The probe acts as one plate of a transformer, with the conductive shaft acting as a shorted secondary. Changes in gap alter the coupling coefficient, changing the coil’s impedance.
Installation Requirements
Ensure adequate clearance around the probe body to prevent electrical arcing to grounded surfaces. Verify that the total system length matches the proximitor’s calibration specification.
Usage Precautions
Inspect the probe tip for scratches or pitting before installation, as surface damage can cause signal non-linearity. Keep the cable away from sharp edges and hot exhaust pipes.
