Description
Motorola MVME162-512
Technical Specifications:
- Brand: Motorola
- Model: MVME162-512
- Bus Standard: 6U VMEbus (P1/P2 Connectors)
- Processor Family: 68040-family (EC/LC variants)
Functional Features:
- Drop-in Compatibility: Perfectly fits standard 19-inch VME card cages without altering backplanes or enclosures.
- Rich On-board Interfaces: Integrates async serial I/O (EIA-232/422) for connecting PLCs, HMIs, and tool interfaces.
- Persistent Configuration: On-board Boot firmware (162Bug), NVRAM, and RTC ensure rapid system booting and configuration retention.
- Mature MRO Support: Widespread parts availability and straightforward field replaceability significantly reduce maintenance downtime.
Application Scenarios:
Primarily used in semiconductor process tools, industrial machinery motion control, rail transit subsystems, and laboratory ATE test stands.
Performance Parameters:
- Power Requirements: +5 VDC supplied via VME backplane
- Communication Interfaces: 10Base-T Ethernet (select configurations), SCSI-2, RS-232/422
- Installation Method: Slide-in 6U VME slot, secured with front-panel screws
Material Composition:
Constructed with high-temperature flame-retardant housing. Core chips meet automotive or industrial-grade standards, ensuring stability under extreme conditions.
Structural Characteristics:
Compact 6U Eurocard packaging with clear silkscreen markings. Supports standard I/O cabling via MVME712 series transition modules.
Working Principle:
Acts as the core controller, interacting with other I/O modules via the VME backplane. The 162Bug firmware manages hardware initialization, memory testing, and OS loading.
Installation Requirements:
Use a standard 6U VME chassis with card guides. Maintain unobstructed airflow; typically, 30-50 LFM per slot is sufficient for cooling.
Usage Precautions:
Always ensure backplane power is completely off before inserting or removing modules. Verify hardware revisions and jumper settings when replacing boards to ensure compatibility with existing software BSPs.
