Description
Motorola MVME712/M
Technical Specifications:
- Brand: Motorola
- Model: MVME712/M
- Type: IndustryPack Carrier Board
- Slot Quantity: Supports up to 4 single-width or 2 double-width IndustryPack modules
Functional Features:
- Flexible I/O Expansion: Allows users to freely combine serial, parallel, CAN bus, or A/D conversion modules based on specific needs.
- Space Saving: Consolidates multiple I/O functions into a single VME slot, maximizing backplane resource utilization.
- Plug-and-Play: Provides standard VME address mapping to simplify system integration.
Application Scenarios:
Any VME control system requiring extensive field I/O connections, such as data acquisition stations and PLC expansion racks.
Performance Parameters:
- Data Transmission: Supports VME A16/A24 addressing and D16/D32 data transfers
- Isolation Protection: Select I/O channels provide optoelectronic isolation
Material Composition:
Utilizes high-reliability connectors to ensure contacts are not damaged during frequent insertion and extraction of IndustryPack modules.
Structural Characteristics:
Standard 6U VME size with front panel cutouts precisely aligned to IndustryPack module interfaces.
Working Principle:
Receives read/write commands from the master controller via the VME bus and routes them to the designated IndustryPack slot. Simultaneously provides necessary interrupt arbitration and DMA channels.
Installation Requirements:
When installing IndustryPack modules, align them with the guide rails and apply even pressure to avoid bending pins. Secure screws must be tightened to the appropriate torque.
Usage Precautions:
Different IndustryPack modules may require different VME address spaces; consult the manual carefully during configuration to avoid address conflicts.
