Description
Woodward 2301A 9907-018
Technical Specifications
- Brand: Woodward
- Part Number: 9907-018
- Product Type: Digital Speed/Load Controller
Functional Features
- PID Control: Advanced Proportional-Integral-Derivative algorithms for stable operation.
- Actuator Driving: Directly drives 4-20mA or 0-10VDC electronic actuators.
- Communication: RS-232 port for PC-based monitoring and configuration.
Application Scenarios
Widely utilized in diesel generator sets, gas engines, and mechanical drive applications.
Performance Parameters
- Speed Droop: Adjustable droop settings for stable parallel operation.
- Accuracy: High-precision speed and load regulation.
Material Composition
Rugged metal enclosure with conformal-coated internal electronics.
Structural Characteristics
Standard MicroNet chassis form factor with plug-in terminal strips.
Working Principle
Continuously monitors engine RPM and electrical load, calculating the exact fuel requirement and outputting the corresponding signal to the actuator.
Installation Requirements
Wire the speed sensor with shielded cable, grounded at the controller end only.
Usage Precautions
Perform a full functional test of all protection circuits before placing the engine in service.
