Product Introduction:
The ABB CI854A is a PROFIBUS DP communication adapter specifically designed for the ABB S800 I/O system. It enables the S800 I/O station to function as a standard PROFIBUS DP slave, integrating seamlessly with major PLC platforms.

Request Quote
Category: SKU: ABB CI854A 3BSE030220R1

Description

ABB CI854A 3BSE030220R1

Technical Specifications:

  • Protocol: PROFIBUS DP-V0/V1.
  • Max Baud Rate: 12 Mbps.
  • Order Code: 3BSE030220R1.

Functional Features:

  • Plug-and-Play: Simplifies GSD file integration and station configuration.
  • Advanced Diagnostics: Detailed bus fault reporting via LED indicators and software.
  • High Data Capacity: Supports large process data maps for complex I/O stations.

Application Scenarios:

  • Distributed automation in automotive, packaging, and general manufacturing.
  • Retrofitting legacy systems with modern PROFIBUS networks.

Performance Parameters:

  • Deterministic Response: Guaranteed cyclic data exchange.
  • Acyclic Access: Supports DP-V1 for alarm handling and parameter access.

Material Composition & Structural Features:

  • Connectors: Dual DB9 female connectors for bus in/out.
  • Indicators: RUN, ERR, and bus activity LEDs.

Working Principle:
Maps S800 I/O data into PROFIBUS DP telegram slots, responding to master polls with real-time process values.

Installation Requirements:

  • Set station address via rotary DIP switches before powering up.
  • Use proper PROFIBUS cabling with correct termination.

Usage Precautions:

  • Ensure the GSD file matches the CI854A hardware revision.
  • Keep bus cables away from high-voltage motor cables.
