Product Brief Introduction

CM-MPS is ABB modular three-phase multi-function monitoring relay, used for real-time monitoring of three-phase AC power supply quality of industrial equipment, detect phase loss, phase sequence error, overvoltage, undervoltage, three-phase unbalance fault of power supply, cut off equipment power supply or trigger alarm when abnormal power supply occurs, widely used for motor, frequency converter, automation equipment power supply protectioneero

Request Quote
Category: SKU: ABB CM-MPS

Description

ABB CM-MPS



Technical Specifications & Performance Parameters

  1. Installation Form: Standard 35mm DIN rail mounting, single module width
  2. Power Supply Input Specifications (Multiple Models Optional):
    • CM-MPS 160–300VAC three-phase without neutral wire
    • CM-MPS 300–500VAC high-voltage three-phase model
    • CM-MPS 180–280VAC with neutral wire monitoring version
  3. Frequency Adaptation: Dual frequency 50Hz / 60Hz automatic identification
  4. Adjustable Protection Parameters:
    • Overvoltage/undervoltage threshold: ±5% ~ ±20% rated voltage continuously adjustable
    • Three-phase unbalance threshold: 2% ~ 15% adjustable
    • Action delay time: 0.1s ~ 10s continuous rotary knob adjustment
  5. Output Contact Parameter: 1 SPDT relay output contact, rated load 8A@250VAC resistive load
  6. Environmental Parameters: Operating temperature -20°C ~ +60°C; storage -40°C ~ +70°C
  7. Protection Grade: IP20, cabinet internal installation
  8. Certifications: CE, UL, IEC 60947-5-1 low-voltage electrical standard certified



Function Characteristics

  1. All-round three-phase power supply fault monitoring: phase loss, reverse phase sequence, overvoltage, undervoltage, three-phase voltage unbalance, neutral wire breakage (optional version)
  2. Full parameter mechanical knob adjustment on front panel, no need to connect upper computer software for parameter setting
  3. Adjustable action delay time, avoid false alarm caused by instantaneous power supply fluctuation
  4. Independent SPDT relay output contact, can directly drive alarm horn or contactor trip coil
  5. Multi-group LED status indicators: power supply normal, fault trigger, three-phase voltage status
  6. Optional sealable parameter adjustment cover, prevent on-site personnel random modification of protection threshold
  7. Short-circuit protection of internal sampling circuit, avoid module burnout caused by power supply wiring error



Material Composition

  1. Outer casing: Black flame-retardant ABS DIN rail shell, integrated elastic rail buckle
  2. Internal circuit board: FR4 anti-interference PCB, voltage sampling resistance network and comparison chip
  3. Adjustment components: Metal rotary potentiometer knobs with scale marks for parameter adjustment
  4. Relay output unit: Industrial electromagnetic relay with silver alloy contact
  5. Wiring terminals: Screw-type nickel-plated copper terminals, three-phase power input and output contact partition layout
