ABB DSPC170
ABB DSPC170 - Image 2

ABB DSPC170

Product Overview:
The ABB DSPC170 (commonly associated with the ordering code 57310001-GL) is the central processing unit (CPU) board for the ABB Advant OCS and MasterPiece 200 series control systems. It acts as the core “brain” of the industrial control system, executing complex logic, managing real-time tasks, and coordinating communication across the entire network.

Request Quote
Category: SKU: ABB DSPC170

Description

ABB DSPC170

Technical Specifications:

  • Processor Architecture: Features an advanced dual-core processor architecture for high-speed multitasking.
  • Memory Capacity: Equipped with large-capacity memory to handle extensive control programs and historical data logging.
  • System Compatibility: Designed specifically for ABB Advant OCS, MasterPiece 200, and 200/1 series systems.
  • Physical Dimensions: Standard board size with a depth of 297 mm, height of 31.5 mm, and width of 229.5 mm.
  • Weight: Weighs approximately 0.915 kg.

Functional Features:

  • Real-Time Multitasking: Capable of executing multiple control loops and communication tasks simultaneously with microsecond-level response times.
  • Advanced Communication: Supports a wide variety of industrial communication protocols for seamless integration with HMIs, SCADA systems, and other intelligent devices.
  • High-Precision Control: Optimized for complex process control algorithms, ensuring accurate regulation of industrial processes.
  • Extensive Diagnostics: Provides comprehensive system health monitoring and fault diagnostics to minimize downtime.

Application Scenarios:

  • Heavy Industry: Widely used in steel manufacturing, cement production, and paper mills for continuous process control.
  • Power Generation: Manages complex control strategies in thermal and hydroelectric power plants.
  • Chemical Processing: Ensures precise control of batch processes, temperature, pressure, and flow in chemical reactors.
  • System Upgrades: Serves as a high-performance replacement or upgrade for legacy Advant OCS controllers.

Performance Parameters:

  • Processing Speed: High clock speeds and dual-core architecture enable rapid execution of complex PID loops and logic.
  • Data Throughput: High-bandwidth backplane communication ensures fast data exchange between I/O modules and the CPU.
  • Reliability: Industrial-grade components ensure stable operation in environments with high electrical noise and temperature fluctuations.

Material Composition & Structural Characteristics:

  • Circuit Board: Multi-layer printed circuit board (PCB) with high-density surface-mount components.
  • Connectors: Robust backplane edge connectors and front-panel interfaces for reliable electrical connections.
  • Thermal Management: Integrated heat sinks and strategic component placement to dissipate heat generated by the dual-core processor.
  • Compliance: Manufactured in compliance with RoHS environmental standards.

Working Principle:
The DSPC170 continuously scans the status of all connected input modules via the backplane. It executes the user-programmed control logic (ladder logic, function blocks, etc.) using its dual-core processor. Based on the logic results, it updates the output modules to control field devices. Simultaneously, it manages network traffic, handles data logging, and responds to operator commands from the HMI.

Installation Requirements:

  • Backplane Seating: Carefully align the board with the backplane slot and use the extraction levers to ensure a secure, fully seated connection.
  • Cooling Airflow: Ensure the control panel has adequate ventilation and unobstructed airflow across the processor board to prevent overheating.
  • Firmware Loading: Load the appropriate system firmware and control application program before placing the system into operational mode.
  • Grounding: Verify that the control panel chassis and backplane are properly grounded to protect against electrical transients.

Usage Precautions:

  • Electrostatic Discharge (ESD): Always use an ESD wrist strap and mat when handling or installing the processor board to prevent damage to sensitive microelectronics.
  • Battery Maintenance: If the board utilizes a backup battery for memory retention, replace it according to the manufacturer’s recommended schedule to prevent program loss.
  • Firmware Updates: Only perform firmware updates using verified files and following strict procedures to avoid bricking the controller.
  • Environmental Protection: Keep the control panel doors closed to prevent dust accumulation, which can lead to overheating and short circuits.
