Description
ABB 1TGE120028R0010
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 1TGE120028R0010 |
| Brand | ABB |
| Type | Low-Voltage VFD / HMI Touch Panel |
| Input Voltage | Three-phase 380V-480V AC |
| Output Voltage | Three-phase 380V-480V AC |
| Output Frequency | 0.5Hz – 590Hz |
| Rated Power | 0.75kW – 22kW |
| Control Method | Vector control |
| Display | 6-digit 7-segment LED / Touchscreen (model dependent) |
| Communication | Ethernet (10/100Mbps), Profibus |
| Protection Functions | Overcurrent, overvoltage, overheating, short-circuit |
| Protection Level | IP65 (front panel) |
| Operating Temperature | -10°C to +60°C (some variants -40°C to +70°C) |
| Storage Temperature | -25°C to +65°C (some variants -40°C to +85°C) |
| Dimensions | 150mm×100mm or 247mm×185mm×82mm |
| Weight | 322g – 5kg |
| Certification | CE |
Function Features
- High-Precision Vector Control: Precise motor speed and torque regulation for high dynamic response applications
- Wide Frequency Range: 0.5Hz to 590Hz output covers full-range speed regulation from low to high speeds
- Comprehensive Protection: Built-in overcurrent, overvoltage, overheating, and short-circuit protection with automatic fault detection
- Fault Location: Some models support short-circuit fault point location in networks
- Flexible Communication: Ethernet and Profibus support for seamless DCS/PLC integration
- Modular Design: Supports multi-device cascading and remote monitoring
- User-Friendly Interface: LED display or touchscreen for real-time status and parameter monitoring
Application Scenarios
- Motor control in manufacturing and process industries
- Conveyor systems and pumping stations
- HVAC systems and building automation
- Energy management systems
- MNS iS switchgear systems
Working Principle
The drive uses vector control algorithms to precisely regulate motor frequency and voltage. It converts fixed-frequency AC power to variable-frequency AC power through IGBT switching, enabling precise speed control. The integrated control logic monitors motor parameters in real-time and triggers protective actions when abnormal conditions are detected.
Installation Requirements
- Install in ventilated control cabinets with adequate airflow
- Maintain ambient temperature within specified ranges
- Use proper cable shielding for motor and communication connections
- Ensure correct grounding for safety and EMI compliance
Usage Notes
- Verify input voltage matches local power supply
- Configure motor parameters correctly before operation
- Regularly check for dust accumulation on cooling vents
- Monitor operating temperature to prevent overheating
- Update firmware to latest compatible version
