Description
Bently 3300/03-01-00
Technical Specifications
- Sensor Type: 3300 XL 8mm Proximity Probe
- System Length: 1.0 meter (3.3 feet)
- Thread Specification: Standard M10x1
Functional Features
- Compact Profile: Designed for applications with standard axial clearance in the bearing housing.
- Standard Sensitivity: Delivers the industry-standard 200 mV/mil output for seamless integration with monitoring modules.
- Reliable Connection: Utilizes proven ClickLoc connector technology for secure signal transmission.
Application Scenarios
Commonly used on smaller pumps, fans, and auxiliary equipment for continuous condition monitoring.
Performance Parameters
- Sensitivity: 7.87 V/mm (200 mV/mil) ±5%
- Linear Range: 2.0 mm (80 mils)
- Frequency Response: DC to 10 kHz
- Operating Temperature: -51°C to +177°C
Material Composition
Precision-machined stainless steel body, high-temperature dielectric tip, and shielded micro-coaxial cabling.
Structural Characteristics
Standard 8mm diameter profile with M10x1 mounting threads and an integrated 1.0-meter cable assembly.
Working Principle
Operates as a non-contact sensor, translating the physical gap between the probe tip and the rotating shaft into a linearized electrical signal.
Installation Requirements
Ensure the combined length of the probe and extension cable exactly matches the 1.0-meter system specification.
Usage Precautions
Avoid pulling or twisting the cable during installation. Protect the connector from mechanical damage and fluid contamination.
