Description
Bently 330103-00-05-05-02-00
Technical Specifications
- Sensor Type: 3300 XL 8mm Proximity Probe
- Thread Length: 50 mm (M10x1)
- Smooth Length: 50 mm
- System Length: 1.0 meter (3.3 feet)
Functional Features
- Ultra-Compact Design: The short 50mm smooth length is specifically engineered for bearing housings with severe axial space limitations.
- High Precision: Maintains the standard 200 mV/mil sensitivity and 2.0 mm linear range despite the compact form factor.
- Seamless Integration: Fully compatible with all 3300 XL 8mm Proximitor transducers and 3500 monitor modules.
Application Scenarios
Ideal for specialized machinery, auxiliary gearboxes, and compact industrial fans where standard probe lengths cannot be accommodated.
Performance Parameters
- Sensitivity: 7.87 V/mm (200 mV/mil) ±5%
- Linear Range: 2.0 mm (80 mils)
- Frequency Response: DC to 10 kHz
- Operating Temperature: -51°C to +177°C
Material Composition
Stainless steel housing, high-temperature PEEK sensing tip, and specialized shielded coaxial cable.
Structural Characteristics
Compact cylindrical probe body with M10x1 threads, a short smooth section, and an integrated 1.0-meter cable assembly.
Working Principle
Generates a high-frequency electromagnetic field at the probe tip, translating the physical gap between the probe tip and the rotating shaft into a linearized electrical signal.
Installation Requirements
Thread the probe into the bearing housing using the specified torque. Verify that the 50mm smooth section clears the internal housing without interference.
Usage Precautions
Clean the mating threads and connector with an appropriate solvent before assembly. Apply thread sealant to prevent oil leakage into the housing.
