Bently 330103‑00‑08‑10‑02‑CN

Bently 330103‑00‑08‑10‑02‑CN

Product Brief Introduction: This is 3300‑XL 8 mm proximity probe with CN suffix for Chinese hazardous‑area compliance approval. It adopts full‑thread M10×1 housing, 80 mm case length, 1.0 m integrated non‑armored cable, ClickLoc miniature coaxial connector without protector sleeve. It executes non‑contact displacement and vibration measurement for critical rotating equipment, meets domestic project acceptance requirements together with international API 670, IECEx and NEPSI safety certification standards.

Request Quote
Category:

Description

Bently 330103‑00‑08‑10‑02‑CN

Technical Specifications:

  • Sensing Tip Diameter: 8 mm
  • Thread Specification: M10 × 1 metric full‑thread housing
  • Unthreaded Segment Length: 0 mm
  • Overall Probe Case Length: 80 mm
  • Integrated Probe Cable Length: 1.0 meter
  • Connector Type: ClickLoc miniature coaxial connector, no connector protector
  • Sensitivity: 7.87 V/mm
  • Linear Measurement Range: 0.25 mm ~ 2.30 mm
  • Recommended Operating Gap: 1.27 mm (50 mils)
  • Frequency Response: 0 Hz to 10 kHz
  • Probe Operating Temperature: ‑52 °C ~ +177 °C
  • Cable Operating Temperature: ‑52 °C ~ +177 °C
  • System Supply Voltage: ‑17.5 Vdc ~ ‑26 Vdc
  • Max Working Current: 12 mA
  • Certifications: CE, UL, IECEx, NEPSI China hazardous‑area certification Functional Features:
  • Non‑contact eddy‑current sensing without mechanical contact wear
  • Stable 7.87 V/mm sensitivity across full linear operating window
  • ClickLoc gold‑plated quick‑lock connector for fast field connection
  • CN certification satisfies Chinese domestic bidding, inspection and acceptance specification
  • Compatible with 3300‑XL Proximitor sensor, Bently 3500 machinery protection rack and System 1 analysis software
  • Measures radial vibration, axial thrust position, rotor eccentricity and Keyphasor speed‑phase trigger signal
  • Excellent anti‑interference performance for high‑EMI industrial field environment
  • Field interchangeable with other qualified 3300‑XL series proximity probe assemblies Application Scenarios:
  • Steam turbine, centrifugal compressor shaft‑vibration monitoring for Chinese domestic power and petrochemical projects
  • Thrust‑position monitoring for fluid‑film bearing rotating machinery requiring NEPSI hazardous‑area approval
  • Large‑size fan, pump and turbo‑generator unit online condition‑monitoring system
  • Refinery, coal‑chemical and natural‑gas plant machinery protection projects with local safety‑certification requirement Performance Parameters:
  • Measurement Non‑linearity: Less than ±1.5 % of full linear range
  • Repeatability: Better than ±0.02 mm
  • Target Material Requirement: AISI‑4140 steel or equivalent conductive alloy
  • Minimum Target Surface Diameter: 21 mm
  • Output Signal: Negative DC voltage proportional to gap distance
  • Cable Capacitance: 69.9 pF/m nominal Material Composition:
  • Probe Tip Core: Polyphenylene sulfide (PPS) high‑temperature insulating polymer
  • Probe Housing Body: AISI 304 stainless‑steel machined alloy
  • Internal Sensing Coil: High‑stability enamel‑wound copper coil
  • Probe Cable Insulation: Fluoropolymer high‑temperature resistant insulating material
  • Connector Shell: Gold‑plated nickel‑plated alloy Structural Characteristics:
  • Fully‑threaded M10 × 1 cylindrical probe housing, zero unthreaded section
  • Sensing coil hermetically encapsulated inside probe tip polymer housing
  • Non‑armored flexible fluoropolymer‑insulated cable directly exits probe rear end
  • Rear‑mounted ClickLoc miniature coaxial quick‑lock connector without external protective sleeve
  • Metric thread structure for direct installation into machine housing tapped hole Working Principle: Proximitor sensor transmits high‑frequency excitation signal to probe internal coil, generating alternating magnetic field at probe tip. Eddy current is induced on surface of nearby conductive metallic target, consuming magnetic‑field energy and changing probe coil impedance. Proximitor circuit converts impedance variation into DC output voltage linearly corresponding to physical gap between probe tip and shaft target surface, realizing static position and dynamic vibration signal acquisition. Installation Requirements:
  • Install probe strictly perpendicular to rotating shaft target surface, angular offset cannot exceed 1‑degree
  • Screw probe body into M10 × 1 tapped hole on bearing housing, avoid excessive tightening torque
  • Adjust static gap to 1.27 mm before unit commissioning
  • Fasten ClickLoc connector by finger‑tight rotation until audible click locking feedback
  • Ensure total length sum of probe cable and extension cable matches Proximitor factory‑calibrated system length
  • Guarantee sufficient clearance between probe tip and rotating shaft to eliminate collision risk
  • Separate signal cable from high‑voltage power wiring with minimum 150 mm clearance
  • Apply cable clamps to support cable, eliminate pulling tension acting on probe housing Usage Notes:
  • Probe tip polymer surface must avoid mechanical impact, scratch and abrasive particle erosion
  • Do not cut or modify factory‑integrated probe cable length on‑site
  • Only deploy genuine 3300‑XL matched extension cable and Proximitor sensor
  • Since this model excludes connector protector, take extra precautions to prevent connector pin contamination and physical damage
  • Keep connector region away from machine oil, water vapor and corrosive chemical vapors
  • Verify probe gap‑voltage reading during each overhaul cycle to validate transducer loop integrity
