Bently 3500/15 106M1079-01, 127610-01
Technical Specifications
- Module Type: Universal AC Power Supply
- Input Voltage: 85 to 264 VAC RMS (Universal)
- Input Frequency: 47 to 63 Hz
- Output: Regulated DC for 3500 backplane
Functional Features
- Universal Input: Accepts a wide range of global AC voltages without manual switching.
- Redundancy Support: Designed to operate in parallel with a second power supply for N+1 redundancy.
- Self-Monitoring: Continuously monitors output voltage and reports “Power Good” status via front-panel LED.
Application Scenarios
Serves as the primary or redundant power source for 3500 racks in power generation, petrochemical, and manufacturing facilities worldwide.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C (-22°F to +149°F)
- Power Consumption: Highly efficient switching topology
- Protection: Over-voltage, over-current, and short-circuit protection
Material Composition
Built with industrial-grade power electronics, high-capacity filtering capacitors, and robust thermal management components.
Structural Characteristics
Standard half-height 3500 module form factor with front-panel AC input connector, “Power Good” LED, and rear DC output bus connections.
Working Principle
Utilizes switch-mode power supply technology to convert AC input to regulated DC output through rectification, high-frequency switching, and feedback-controlled regulation.
Installation Requirements
Install in the designated leftmost power supply slot of the 3500 rack. Connect AC input using properly rated conductors and ensure adequate ventilation.
Usage Precautions
Verify AC input voltage is within the universal range before energizing. In redundant configurations, use independent AC sources. Never remove the module while energized.
