Description
Bently 330104-00-05-10-02-CN
Technical Specifications
- Model: 330104-00-05-10-02-CN
- Sensor Type: Eddy Current Radial Vibration Probe
- Cable Length: 5.0 meters (indicated by “05”)
- Certification: CN variant (China-specific)
Functional Features
- Radial Vibration Measurement: Optimized for measuring shaft orbit and relative vibration.
- High Frequency Response: Captures detailed vibration waveforms for diagnostic analysis.
- Robust Construction: Designed for harsh industrial environments.
Application Scenarios
Installed at X-Y pairs on bearing housings of all rotating machinery for comprehensive vibration monitoring and protection.
Performance Parameters
- Sensitivity: 7.87 mV/μm (200 mV/mil)
- Operating Temperature: -52°C to +177°C
- Frequency Response: DC to 10 kHz
Material Composition
PPS tip encapsulation, high-purity copper coil, shielded cable with flame-retardant jacket.
Structural Characteristics
Cylindrical probe body with integrated 5-meter cable and connector, optimized for radial mounting.
Working Principle
Eddy current effect: RF magnetic field induces eddy currents in shaft, impedance change proportional to radial gap is converted to voltage signal.
Installation Requirements
Mount in radial orientation on bearing housing. Maintain proper gap voltage. Install in X-Y pair configuration with 90-degree separation.
Precautions for Use
Do not bend cable sharply at probe base. Ensure probe is securely tightened. Verify system sensitivity matches probe specification.
