Description
Bently 10244-27-50-01
Technical Specifications
- Model: 10244-27-50-01
- Function: RF Excitation and Signal Conditioning
- Output: DC voltage proportional to gap
- Power Supply: Standard 3300 series power requirements
Functional Features
- RF Generation: Generates stable high-frequency signal for probe excitation.
- Demodulation: Converts probe impedance changes to linear DC voltage.
- Temperature Compensation: Internal compensation ensures accuracy across temperature ranges.
Application Scenarios
Mounted in control cabinets or junction boxes, interfacing between proximity probes and monitoring modules.
Performance Parameters
- Sensitivity: Matched to probe specifications
- Linearity: ±1% or better over specified range
- Operating Temperature: -40°C to +85°C
Material Composition
Industrial-grade electronic components in aluminum or plastic housing with EMI shielding.
Structural Characteristics
Compact module with BNC or micro-coaxial input connectors and terminal block or connector output.
Working Principle
Generates RF signal, sends to probe, receives reflected signal, demodulates to extract gap information, and outputs conditioned DC voltage.
Installation Requirements
Mount in appropriate enclosure. Connect probe cable and output wiring per wiring diagram. Ensure proper grounding.
Precautions for Use
Match proximitors sensitivity to probe type. Avoid routing cables near high-power equipment. Verify output voltage at known gap during commissioning.
