Description
Bently 3500/45-01-00
Technical Specifications
- Module Type: 4-Channel Position Monitor Module
- Configuration Code: 01-00 (Standard Configuration)
- Channel Count: 4 independent channels
- Slot Placement: Any available monitor slot
Functional Features
- Industry Standard: The baseline position monitor for the 3500 platform, widely supported and documented.
- Plug-and-Play: Fully compatible with 3500 Rack Configuration Software without requiring special hardware jumpers.
- Reliable Measurement: Proven performance in thousands of installations worldwide for continuous position monitoring.
Application Scenarios
Standard deployment for any 3500 system requiring continuous differential expansion and position monitoring for steam and gas turbines.
Performance Parameters
- Operating Temperature: -30°C to +65°C
- Storage Temperature: -40°C to +85°C
- Humidity: 95% non-condensing
Material Composition
Industrial-grade electronic components with environmental protection coatings.
Structural Characteristics
Full-height module with front-panel LEDs indicating the status of each channel and overall module health.
Working Principle
Processes proximity probe signals to generate position measurements, triggering alarms when configured thresholds are exceeded.
Installation Requirements
Install in any available monitor slot. Ensure proper sensor gap and cabling.
