Emerson SE3007
Technical Specifications:
- Brand: Emerson
- Product Series: DeltaV S-Series
- Product Type: SX Controller Module
- User Memory: 96 MB
- Power Supply: Via DeltaV S-Series backplane, nominal 24 VDC
- Typical Power Consumption: 5.0 W (max 7.0 W)
- Internal Fuse: 3.0 A non-replaceable
- Ethernet Ports: Full duplex, 100 MB/second maximum throughput
- Module Execution Rates: 100 ms, 200 ms, 500 ms, 1 s, 2 s, 5 s, 10 s, 30 s, 60 s
- Data Processing: Daylight saving time limit 1500, SCADA tags 3200, sending data values up to 4000 per second, receiving data values 500 per second
- Client Node Support: Up to 120 unrequested client nodes
- Operating Temperature: –40°C to +60°C
- Storage Temperature: –40°C to +85°C
- Relative Humidity: 5% to 95% (non-condensing)
- Communication Interfaces: Dual redundant DeltaV control network ports (10/100 Mbps)
- Signal I/O Types: Analog (AI/AO), Discrete (DI/DO), HART, FOUNDATION Fieldbus
- Redundancy: 1:1 controller redundancy with bumpless switchover
- EMC Standard: EN50081/50082
Functional Features:
- Self-Addressing: Automatically identifies itself to the DeltaV control network upon power-up; no DIP switches or manual configuration required
- Self-Locating: Face-mounted LEDs can be made to flash for easy physical identification
- Automatic I/O Detection: Identifies all I/O interface channels on the subsystem automatically
- CHARM and Wireless I/O Support: Starting from DeltaV v14.3, supports CHARMs and wireless devices through CIOC and WIOC cards
- Data Pass-Through: Passes HART information from field devices to any workstation node
- Data Protection: All online parameter changes are automatically stored for upload to the engineering database
- Batch and Advanced Control: Equipped to handle DeltaV Batch option and advanced control functions
- Scalable Licensing: Expandable from 50 to 750 device signal tags (DSTs)
Application Scenarios:
- Chemical Processing: Continuous and batch process control
- Oil and Gas: Refinery process control and pipeline management
- Power Generation: Boiler and turbine control systems
- Pharmaceutical: Batch manufacturing process control
- Water Treatment: Plant-wide process automation
Material Composition:
- Industrial-grade processor and memory components
- High-quality multi-layer PCB
- Modular enclosure with snap-in mounting mechanism
Structural Features:
- DeltaV S-Series controller carrier/baseplate compatible
- DIN rail snap-in installation (no screws required)
- Dual redundant Ethernet ports
- Status indicator LEDs on the face panel
- Field wiring through I/O modules, not on the controller front
Working Principle:
The SE3007 controller executes control strategies at configurable scan rates, reading process variables from I/O modules via the backplane, performing control calculations, and writing output values to actuator channels. It manages all communication functions on the DeltaV control network and maintains time-stamped alarm and trend data. In redundant configurations, the standby controller mirrors all data and takes over seamlessly upon primary controller failure.
Installation Requirements:
- Snap into the S-Series controller carrier/baseplate on DIN rail
- Connect dual redundant Ethernet cables to the DeltaV control network
- Ensure adequate ventilation for thermal management
- Verify backplane power supply capacity
Usage Precautions:
- Configure redundancy pair before commissioning
- Ensure firmware version compatibility with the DeltaV system
- Monitor CPU utilization to maintain adequate control strategy capacity
- Back up configuration data regularly
