Description
Foxboro FBM217 P0916PW Technical Specifications:
- Module Type: Discrete Input (DI).
- Terminal Base: P0916PW.
- Signal Type: Dry contact / Voltage sensing.
- System: Foxboro I/A Series.
Functional Features:
- Flexible Wiring: Supports specific terminal configurations for P0916PW.
- Reliable Sensing: Accurate detection of discrete state changes.
- System Integration: Plug-and-play compatibility with I/A Series controllers.
Application Scenarios:
- Plant-wide discrete status monitoring.
- Equipment interlocking and sequencing.
- Alarm annunciation inputs.
Performance Parameters:
- Response Time: Millisecond-level state change detection.
- Noise Immunity: High immunity to electrical transients.
Material Composition & Structural Characteristics:
- Base: P0916PW terminal block with robust screw terminals.
- Module: Standard FBM217 electronic assembly.
Working Principle: Operates identically to other FBM217 variants, converting physical contact states into digital data via isolated input circuits.
Installation Requirements:
- Ensure correct alignment of the module on the P0916PW base.
- Torque terminal screws to specification to prevent loose connections.
Usage Precautions:
- Confirm the specific voltage and current ratings of the P0916PW base.
- Label all field wires clearly at the terminal block.
