Foxboro P0916PH P0916JS
Technical Specifications
- Hardware Code: P0916PH / P0916JS.
- Communication Interface: Foxboro Module Fieldbus.
- Power Supply: 24 VDC backplane power with redundancy support.
- Installation: Single-width 200 Series FBM.
Functional Features
- Native Compatibility: Natively compatible with I/A Series controllers and upper-level monitoring software.
- Online Maintenance: Hot-swappable design reduces process disruption.
- High Availability: Supports redundant I/A node configurations.
- Health Monitoring: Integrated diagnostics for proactive maintenance.
Application Scenarios
Widely deployed in petrochemical, power generation, and water treatment facilities for continuous process control.
Performance Parameters
- Operating Temperature: 0°C to 60°C.
- Weight: Approximately 0.4 kg.
Material Composition
Durable plastic enclosure with conformal-coated internal circuitry for harsh environment resilience.
Structural Characteristics
- Size: Standard 200 Series FBM footprint.
- Wiring: Flexible field connection via Termination Assemblies.
Working Principle
Serves as a physical and logical gateway, converting field signals to digital data for the controller and translating controller outputs to field actuators.
Installation Requirements
- Install in a clean, ventilated cabinet.
- Align and lock backplane connectors securely.
- Connect field signals to the appropriate TA.
Precautions for Use
- Verify hardware code to prevent firmware mismatches.
- Ensure proper system grounding.
- Handle with ESD-safe practices.
