Foxboro PO961BC/CP40B

Foxboro PO961BC/CP40B

Product Introduction
The PO961BC, commonly referred to as the CP40B, is a foundational control processor in the Foxboro I/A Series DCS. It serves as the primary computing engine for process control stations, executing regulatory control, logic sequencing, and managing fieldbus communications with high reliability.

Request Quote
Category:

Description

Foxboro PO961BC/CP40B

Technical Specifications

  • Processor: 32-bit industrial-grade RISC processor.
  • Instruction Speed: 0.1 µs/Boolean, 0.5 µs/floating-point.
  • Memory: 8 MB program memory, 4 MB data memory.
  • Communication: Ethernet 10/100BaseTX, ControlNet, RS-232.
  • Power: 24 VDC, 10 W.

Functional Features

  • Comprehensive Process Control: Seamlessly executes regulation, logic, timing, and sequence control.
  • Massive I/O Expansion: Supports up to 256 I/O points and remote I/O link expansion.
  • High-Reliability Redundancy: Dual-module parallel architecture supporting hot-standby controller and power supply redundancy.
  • Data Consistency Verification: Bit-by-bit matching technology thoroughly prevents erroneous information transmission.

Application Scenarios
Core control stations in chemical, power, metallurgical, and water treatment industries, compatible with Foxboro InTouch and Wonderware System Platform.

Performance Parameters

  • Operating Temperature: 0°C to 60°C.
  • Storage Temperature: -40°C to 85°C.
  • Protection Rating: IP20, Class G3 harsh environment compliant.

Material Composition
Die-cast aluminum enclosure with excellent EMI shielding and heat dissipation; internal circuits are conformal-coated.

Structural Characteristics

  • Dimensions: 140 mm × 165 mm × 45 mm.
  • Weight: 0.6 kg.
  • Form Factor: Standard I/A Series control processor footprint.

Working Principle
The processor acquires real-time process variables via the high-speed bus, executes embedded control algorithms, dispatches regulation signals to actuators, and maintains high-speed data synchronization with the global control network via 100 Mbps fiber optic Ethernet.

Installation Requirements

  • Must be installed in a compatible I/A Series control rack.
  • Redundant power supplies are required for uninterrupted operation.
  • Ensure control cabinet ventilation; ambient temperature must not exceed 60°C.

Precautions for Use

  • Strictly prohibit forceful拔插 (insertion/removal) of the processor while energized.
  • Complete a full backup of the control logic before firmware upgrades.
  • Regularly inspect and clean cooling passages to prevent overheating.
