Description
Motorola MVME 2304-0143
echnical Specifications
- Base Architecture: PowerPC 603 200 MHz.
- Configuration Code: 0143 exclusive hardware combination.
- Expansion: Supports PMC and PMCspan expansion modules.
Functional Features
- Simplifies OEM hardware selection and inventory management.
- Provides validated system-level compatibility.
- High-bandwidth PCI local bus.
Application Scenarios
Applicable in semiconductor manufacturing, medical imaging, aerospace testing, and industrial automation control.
Performance Parameters
- Meets industrial-grade wide-temperature and high-humidity requirements.
- Low-latency interrupt response mechanism.
Material Composition
Precision surface-mount technology with gold-plated VME edge connectors.
Structural Characteristics
Standard 6U VME size supporting single-slot high-density expansion.
Working Principle
The MPC603 processor executes real-time control algorithms, utilizing the Falcon memory controller for high-throughput data processing and communicating with the system master via the VME interface.
Installation Requirements
- Confirm chassis backplane supports the VME64 specification.
- Connect front panel network and serial cables correctly.
Usage Precautions
- Avoid using incompatible PMC expansion cards.
- Regularly monitor system logs for hardware alerts.
