Motorola MVME147-011
Technical Specifications
- Microprocessor: MC68030.
- Cache: On-chip high-speed cache.
- Bus: Full VMEbus support.
Functional Features
- Optimized performance for specific application needs.
- Supports floating-point coprocessor expansion.
- Acts as a VME bus interrupter and system controller.
Application Scenarios
Applicable in industrial control, test and measurement, and telecom infrastructure requiring higher processing power.
Performance Parameters
- Optimized clock frequency for targeted applications.
- Supports efficient cross-bus DMA data transfers.
Material Composition
Industrial-grade multi-layer PCB with moisture and corrosion-resistant conformal coating.
Structural Characteristics
Standard 6U VME European card supporting processor mezzanine installation.
Working Principle
The MC68030 communicates with VME interface chips via the local bus, initializing peripherals and efficiently handling I/O tasks through interrupts and DMA.
Installation Requirements
- Requires an MVME712 series transition module for I/O breakout.
- Ensure processor mezzanines are correctly installed and locked.
Usage Precautions
- Verify jumper configurations match the system environment before powering up.
- Monitor cooling conditions to keep processor temperatures safe.
