Motorola MVME162P-242L

Motorola MVME162P-242L

Product Introduction
The MVME162P-242L is a standard-configuration controller in the MVME162P2 series. The “L” designation indicates a base configuration optimized for cost-effective, reliable industrial control.

Request Quote
Category:

Description

Motorola MVME162P-242L

Technical Specifications

  • Processor: 25 MHz MC68LC040.
  • Memory: 16MB SDRAM with parity.
  • Storage: 512KB SRAM, 1MB Flash, 8K NVRAM.
  • Interfaces: Dual serial ports, four IP ports.

Functional Features

  • Standard Configuration: Meets most industrial control requirements.
  • Petra ASIC: High-performance memory and interface management.
  • VMEbus: A32/D64 master/slave and system controller.
  • IndustryPack: Flexible I/O expansion support.

Application Scenarios
General industrial control, PLC core processing, data acquisition systems.

Performance Parameters

  • VME: D64 BLT support.
  • Serial: Dual EIA-232-D/EIA-422.
  • Timers: Six 32-bit timers, watchdog.

Material Composition
Industrial PCB with MC68LC040 and Petra ASIC.

Structural Characteristics
Standard 6U VME size with front-panel status indicators.

Working Principle
Processor accesses memory/peripherals via Petra ASIC; ASIC handles VME bus transactions and DMA.

Installation Requirements

  • Proper VME chassis insertion.
  • Hardware switch configuration.
  • Adequate cooling.

Usage Precautions

  • ESD protection.
  • Battery maintenance.
  • Avoid strong EMI.
