Motorola MVME2700-1341
Technical Specifications
- Processor: 266 MHz MPC750-class 32-bit microprocessor
- L1 Cache: 32KB instruction / 32KB data cache
- L2 Cache: 1MB backside cache
- Memory: 64MB ECC DRAM
- Flash Memory: 5MB on-board Flash
- VMEbus Interface: VME64 master/slave
- I/O Transition Module: MVME761
- Front Panel: IEEE 1101 compatible with injector/ejector handles
- Serial Ports: Two or three async, one or two sync/async
- Ethernet: 10BaseT/100BaseTX with PCI DMA
- SCSI: Fast SCSI-2 interface
- NVRAM: 8KB with battery-backed TOD clock
- Timers: Four 32-bit plus watchdog
Key Features
- 266 MHz MPC750 for high-performance computing
- 1MB backside L2 cache
- 64MB ECC DRAM for expanded memory needs
- 5MB Flash memory
- MVME761 I/O transition support
- IEEE 1101 front panel
- On-board debug monitor with self-test
- PMC expansion slot
Application Scenarios Large-scale industrial control, military aerospace systems, telecommunications network equipment, medical imaging systems, scientific data acquisition, embedded database applications
Performance Parameters
- Processor Clock: 266 MHz
- L1 Cache: 32KB + 32KB
- L2 Cache: 1MB
- Memory: 64MB ECC DRAM
- Flash: 5MB
- Ethernet: 10/100Base-TX
- SCSI: Fast SCSI-2
- NVRAM: 8KB with TOD
Material Composition Industrial-grade multi-layer PCB with high-reliability components. 64MB DRAM from qualified suppliers. Enhanced gold-plated connectors. Durable IEEE 1101 front panel construction.
Structural Characteristics Standard 6U VME form factor. IEEE 1101 front panel with injection/ejection mechanism. LED status indicators. P2 connector for MVME761. DRAM mezzanine connector for future expansion.
Working Principle The 266 MHz MPC750 accesses 64MB ECC DRAM through optimized memory controllers. The 1MB L2 cache minimizes memory access latency. The PowerPlus Architecture ASICs ensure efficient data flow between processor, memory, and I/O subsystems.
Installation Requirements VME64 chassis with adequate cooling and power for 64MB memory. P2 backplane must support MVME761 transition module. Proper grounding essential.
Usage Notes 64MB memory supports most demanding embedded applications. Regular ECC monitoring recommended. Ensure proper cooling for sustained 266 MHz operation.
