Description
Motorola MVME5110-2163
Technical Specifications
- Processor: PowerPC 603e running at 166 MHz.
- Memory: 16 MB onboard DRAM.
- Storage: 4 MB Flash memory.
- Interfaces: Dual 10/100Mbps Ethernet, dual serial ports, and PCI local bus.
Functional Features
- Architecture Upgrade: Adopts PowerPC RISC architecture for higher instruction execution efficiency.
- High-Speed Networking: Dual Ethernet ports support network redundancy or high-speed data separation.
- PCI Expansion: Supports PCI bus for connecting modern high-speed peripherals.
Application Scenarios
High-end test equipment, aerospace simulation, critical infrastructure control, and industrial applications requiring high-performance computing.
Performance Parameters
- Processing Power: 166 MHz PowerPC significantly outperforms the MC68060.
- Memory Bandwidth: Optimized memory controller reduces wait states.
- Data Throughput: Multiple DMA channels operate in parallel to maximize system bandwidth.
Material Composition
Premium industrial-grade components subjected to strict burn-in and testing to ensure long-term reliability.
Structural Characteristics
Standard 6U VME size with rich front panel interfaces and clear labeling for easy maintenance and troubleshooting.
Working Principle
Serves as the system core, coordinating the processor, memory, network, and storage to efficiently execute multi-tasking real-time applications.
Installation Requirements
Ensure chassis power supply and cooling meet the demands of high-configuration boards. Correctly configure all interfaces.
Usage Precautions
Monitor system temperature under high loads. Clean chassis dust regularly and follow standard system boot and shutdown procedures.
