OMRON CJ1M-CPU11

OMRON CJ1M-CPU11

Product Introduction: The CJ1M-CPU11 is a compact, high-performance CPU unit for the OMRON CJ1M series PLC. It serves as the central processing core for small to medium-sized automation systems, offering high-speed processing and flexible expansion capabilities.

Request Quote
Category:

Description

OMRON CJ1M-CPU11

Technical Specifications:

  • Brand: OMRON
  • Model: CJ1M-CPU11
  • Product Type: CPU Unit
  • Compatible System: CJ1M Series PLC
  • Program Capacity: 5,000 steps (5K words)
  • Data Memory (DM): 32K words
  • Maximum I/O Points: 160 points
  • Processing Speed: 0.1 μs for LD instructions
  • Floating Point Calculation: 13.3 μs
  • Interrupt Inputs: 1 point (Timed interrupt)
  • Pulse Output: 1 point (PWM)
  • Dimensions: 90 mm (H) × 65 mm (D)
  • Mounting: DIN Rail or Panel Mount

Functional Features:

  • High-speed instruction processing (0.1 μs)
  • Compact 90mm height design
  • Supports structured programming (Function Blocks)
  • Compatible with CX-One integrated tool package
  • Supports up to 128 MB Memory Cards for data logging and backup
  • Built-in serial communications (RS-232C)

Application Scenarios:

  • Small to medium-scale factory automation
  • Packaging machinery
  • Conveyor systems
  • Assembly lines
  • Material handling equipment

Performance Parameters:

  • Program Capacity: 5K steps
  • DM Area: 32K words
  • I/O Capacity: 160 points
  • Instruction Execution Time: 0.1 μs (LD)

Material Composition:

  • High-performance microprocessor
  • Multi-layer printed circuit board
  • Plastic housing with metal shielding

Structural Features: The CPU unit features a compact form factor with a built-in RS-232C port and a slot for Memory Cards. It connects to I/O modules via the CJ1 series bus connector system (no backplane required).

Working Principle: The CJ1M-CPU11 executes user programs stored in its memory, reads input signals from connected I/O units, performs logic and arithmetic operations, and updates output signals. It manages data exchange between the CPU, I/O modules, and communication networks.

Installation Requirements:

  • Mount on DIN rail or panel
  • Connect I/O modules to the right of the CPU
  • Connect power supply unit (CJ1W-PA/PD) to the left of the CPU
  • Ensure proper grounding

Usage Notes:

  • Use CX-Programmer version 3.3 or higher for programming.
  • Ensure the total current consumption of the system is within the power supply unit’s capacity.
  • Do not install the CPU in environments with excessive vibration or corrosive gases.
