OMRON F350
Technical Specifications:
- Brand: OMRON (Note: F350 is also associated with UNIPULSE brand)
- Model: F350
- Product Type: 2-Channel Input Digital Indicator
- Input Type: Strain gauge type sensor (2 channels)
- Sampling Speed: 3000 times/sec. per channel (switchable to 300 times/sec.)
- Form Factor: DIN 96 square size
- Calculation Functions: ch1+ch2, ch1-ch2, |ch1-ch2|, High select, Low select
- Judgment Outputs: 9 points (HI/OK/LO for calculated value, HI/LO/Alarm for ch1, HI/LO/Alarm for ch2)
- Analog Monitor Output: Voltage proportional to input signal (per channel)
- Display: Main display (calculated value) + Sub display (ch1, ch2 input values)
Functional Features:
- 2-channel input for strain gauge sensors
- High-speed sampling at 3000 times/sec. per channel
- Calculation functions: addition, subtraction, absolute difference, high/low select
- 9 points of judgment outputs with HI/OK/LO comparison
- Digital zero and digital offset functions
- Analog monitor output for recorder connection
- Hold functions: Sample, Peak, Bottom, Average
- Equivalent input calibration (calibration by key input without actual load)
- HI/LO limit comparison with hysteresis to prevent chattering
Application Scenarios:
- Total weight measurement (ch1 + ch2)
- Difference measurement between two load points
- Balance and leveling measurements
- Industrial weighing systems
- Force measurement applications
- Quality control and process monitoring
- Any application requiring dual-channel load comparison
Performance Parameters:
- Input Channels: 2
- Sampling Speed: 3000 times/sec. (switchable to 300 times/sec.)
- Calculation Functions: 5 types
- Judgment Outputs: 9 points
- Display: Main + Sub display
Material Composition:
- Industrial-grade electronic components
- Multi-layer printed circuit board
- Plastic housing (DIN 96 form factor)
- Terminal block connections
Structural Features: The F350 features a compact DIN 96 square form factor for panel mounting. The front panel includes a main display for showing calculated values and a sub display for showing individual channel inputs. Keys allow configuration of parameters, calibration, and function selection.
Working Principle: The F350 receives analog signals from two strain gauge type sensors through its input channels. Each channel is sampled at high speed (3000 times/sec.), converted to digital values, and displayed on the sub display. The unit performs user-selected calculation functions (addition, subtraction, etc.) on the two channel values and displays the result on the main display. Judgment outputs are activated based on configurable HI/LO/OK
