Description
Woodward DPG2201
Technical Specifications
- Model: DPG2201
- Type: Digital Speed / Load Controller
- Control Mode: Programmable Isochronous or Droop
Functional Features
- Digital Precision: Provides highly accurate speed and load control.
- Programmable Logic: Can be configured to match specific prime mover characteristics.
- Diagnostics: Built-in self-diagnostics for predictive maintenance.
Application Scenarios
Used in diesel generator sets, gas engines, and steam turbines requiring precise digital speed and load control.
Performance Parameters
- Speed Regulation: Excellent steady-state and transient response.
- Response Time: Fast digital processing for rapid load acceptance.
Material Composition
Industrial-grade electronics housed in a rugged, flame-retardant enclosure.
Structural Characteristics
- User Interface: Front panel for local monitoring and parameter adjustment.
- I/O Terminals: Clearly labeled terminals for sensors, actuators, and communication.
Working Principle
Samples engine or turbine speed and load parameters, processes the data through internal control algorithms, and outputs precise signals to actuators to maintain the desired setpoints.
Installation Requirements
Mount in a clean, dry environment. Ensure all sensor and actuator wiring is properly shielded and grounded.
Precautions for Use
Verify all parameters are correctly configured for the specific prime mover before initial startup.
