ABB 07AI91E

ABB 07AI91E

Product Introduction: The ABB 07AI91E is a high-performance analog input module designed for ABB Advant Controller 31-based systems. It serves as a critical bridge between field sensors and the control logic, converting analog process signals into digital data for precise monitoring and control. The module plugs into the Advant I/O topology and communicates over the CS31/Advant network, enabling scalable I/O expansion without rewriting control logic. It is designed for control cabinets and decentralized wiring schemes.

Request Quote
Category:

Description

ABB 07AI91E

Technical Specifications:

Parameter Specification
Input Channels 8 configurable analog input channels
Input Signal Types Voltage: -50…+50mV, -500…+500mV, -5…+5V, -10…+10V; Current: 0…20mA; Thermocouple: J, K, S type; RTD: Pt100, Pt1000
Resolution 12-bit + sign
Sampling Rate 1000 S/s per channel
Accuracy ±0.1% F.S.
Input Impedance >1 MΩ (voltage); ~250 Ω (current)
Power Supply 24V DC
Communication Interface CS31/Advant bus interface (fieldbus slave)
Operating Temperature 0°C to +55°C (operating); -25°C to +75°C (storage)
Mounting Standard DIN rail (TH 35-15, TH 35-7.5) per IEC 60715
Protection Class IP20
Cable Cross-Section 0.08…1.5mm²
Certifications CE, CSA, GL, DNV, ABS

Functional Features:

  • Multi-channel analog input with configurable ranges and sampling behavior
  • Channel-to-channel electrical isolation to reduce signal interference
  • Built-in filtering and signal conditioning for noisy industrial environments
  • Channel-level diagnostics for simplified fault isolation
  • Overvoltage and short-circuit protection on all channels
  • Supports interrupt triggering for rapid response to abnormal signals
  • Hot-swappable design for online maintenance

Application Scenarios:

  • Process control in chemical, pharmaceutical, and oil & gas industries
  • Temperature, pressure, flow, and level monitoring in power generation
  • Furnace temperature regulation and rolling mill pressure control in metallurgy
  • Kiln operations and raw material mixing in cement production
  • Water and wastewater treatment process monitoring
  • Food & beverage production line control

Installation Requirements:

  • Mount on standard DIN rail inside enclosed control cabinet
  • Ensure proper ventilation and maintain IP20 protection
  • Use shielded cables for analog signal wiring to minimize EMI
  • Verify CS31 bus termination at network ends

Usage Precautions:

  • Do not exceed 30V DC overvoltage limit on voltage inputs
  • Ensure proper grounding of signal shields at single point
  • Verify battery status if SRAM data retention is required
  • Match firmware revision with existing system modules
