Description
ABB 216NG63A
Technical Specifications:
- Rated Voltage: 6500 V
- Rated Current: 1800 A
- Switching Frequency: 2 kHz
- Switching Losses: 8.0 J
- Conduction Losses: 4.0 V
- Maximum Junction Temperature: 175°C
Functional Features:
- High Efficiency: Significantly reduces power loss and heat generation, optimizing energy utilization.
- High Power Density: Delivers massive power output within a compact physical footprint.
- Surge Protection: Built-in multi-stage protection mechanisms safeguard against lightning strikes and motor startup transients.
- Extended Lifespan: Premium materials and thermal design reduce long-term maintenance costs.
Application Scenarios:
- HVDC converter stations.
- Large-scale wind and solar power generation systems.
- Railway traction systems and heavy industrial motor drives.
- Electric vehicle charging infrastructure and energy storage stations.
Performance Parameters:
- Protection Rating: IP20
- Speed/Torque Range: 0-2000 rpm / 0-3500 Nm (when applied as a drive controller)
Material Composition & Structural Features:
- Dimensions: Length 450 mm x Width 400 mm x Height 300 mm
- Mounting Hole Distance: 400 mm
- Weight: 40 kg
- Structure: Sturdy metal housing with a modular plug-in design for rapid field installation and maintenance.
Working Principle:
As a converter valve module, it utilizes high-frequency power electronic switching devices to precisely convert high-voltage direct current into alternating current or regulate DC voltage, enabling flexible power transmission and distribution.
Installation Requirements:
- Must be installed in electrical cabinets with excellent ventilation and cooling conditions.
- Mounting hole distances must be strictly aligned to ensure even mechanical stress distribution.
Usage Precautions:
- Installation and maintenance must be performed exclusively by qualified high-voltage personnel.
- Regularly inspect cooling channels to prevent overheating caused by dust accumulation.
