Description
ABB 3BHE013299R0002
Technical Specifications:
| Parameter | Value |
|---|---|
| Product Model | 3BHE013299R0002 |
| Manufacturer | ABB |
| Product Category | Control and Communication Board / Drive Control Panel |
| Series | ACS880 Drive Series / ACS Series |
| Display | 7-inch color touchscreen |
| Keyboard | 10 keys |
| Indicators | 5 LED indicators |
| Communication Interface | RS-485 |
| Working Voltage | 24 V DC |
| Operating Temperature | -10°C to +50°C |
| Weight | 0.5 kg |
| Rated Voltage | DC 320 V |
| Rated Current | 25 A |
| Output Power | 960 W |
| Operating Frequency | 47 Hz to 63 Hz |
| Humidity | 95% RH |
| Vibration | 0.5 g (20–500 Hz) |
| Shock | 15 g (11 ms) |
| Insulation Resistance | ≥100 MΩ |
| Dielectric Strength | 2.5 kV AC |
| Mechanical Life | 10,000 operations |
| Electrical Life | 10,000 operations |
Functional Features:
- Intuitive Operation: 7-inch color touchscreen provides user-friendly interface for drive control and monitoring.
- Multi-Function Integration: Handles control signals and communication data transmission within the drive system.
- Real-Time Monitoring: Displays operational parameters, fault diagnostics, and system status.
- Flexible Configuration: Configurable for specific application requirements through software tools.
- High Reliability: Constructed with high-quality components for robust industrial performance.
Application Scenarios:
- Fan and pump control systems
- Compressor drive applications
- Conveyor belt systems
- Mixer and agitator control
- Crane and hoist drives
- Textile machinery
Material and Structure:
- Compact panel-mounted design
- Durable front panel with membrane keyboard
- Industrial-grade touchscreen resistant to chemicals and abrasion
