Description
ABB 3HAC025562-001
Technical Specifications:
- Brand: ABB
- Model Number: 3HAC025562-001
- Product Type: Signal / Control Cable
- Conductor Count: Multi-core design
Functional Features:
- Multi-Signal Transmission: Carries I/O signals, gripper control, and safety interlock signals.
- Noise Immunity: Individually shielded pairs to prevent cross-talk.
Application Scenarios:
- Connecting the controller to the robot’s tool flange I/O.
- Linking safety relays to the robot base.
Performance Parameters:
- Bandwidth: Suitable for high-frequency digital communication.
- Capacitance: Low mutual capacitance for crisp signal edges.
Material Composition & Structural Features:
- Core Insulation: Color-coded for easy identification and troubleshooting.
- Overall Shield: Foil and braid combination for maximum EMI protection.
Working Principle:
Provides dedicated pathways for binary and analog signals, ensuring that safety stops and tool commands are executed reliably without interference from adjacent power cables.
Installation Requirements:
- Route separately from high-voltage power cables.
- Ground the shield at the controller end only (or as specified) to prevent ground loops.
Usage Precautions:
- Avoid splicing or repairing signal cables; replace the entire assembly if damaged.
- Ensure pin assignments match the controller’s I/O configuration.
