Description
ABB 3HAC026272-001
Technical Specifications:
- Brand: ABB
- Model Number: 3HAC026272-001
- Product Type: Safety Hardware / SafeMove Assembly
- Weight: 1.62 kg
- Origin: Germany
Functional Features:
- Advanced Safety Zones: Allows programming of restricted spatial zones where the robot cannot enter.
- Speed Limiting: Dynamically reduces robot speed when personnel enter collaborative areas.
- Redundant Monitoring: Dual-channel architecture for SIL3/PL-e safety compliance.
Application Scenarios:
- Collaborative robot cells where humans and robots share workspace.
- High-speed manufacturing lines requiring dynamic safety boundaries.
Performance Parameters:
- Safety Integrity: Meets IEC 61508 SIL3 and ISO 13849-1 PL-e standards.
- Response Time: Millisecond-level reaction to safety faults.
Material Composition & Structural Features:
- Industrial Enclosure: Rugged housing designed for DIN-rail or backplane mounting.
- Secure Connectors: Locking connectors to prevent accidental disconnection.
Working Principle:
Continuously monitors the robot’s position and speed using redundant encoders. If the robot violates a programmed safety parameter, the assembly instantly triggers a safe torque off (STO) or safe speed reduction.
Installation Requirements:
- Must be installed and configured by certified ABB safety personnel.
- Requires strict adherence to safety wiring diagrams.
Usage Precautions:
- Never bypass or modify the SafeMove assembly.
- Perform regular safety validation tests as per the safety manual.
