ABB AI810 (3BSE008516R0001)
ABB AI810 (3BSE008516R0001) - Image 2

ABB AI810 (3BSE008516R0001)

Product Overview:
The ABB AI810 (Order Code: 3BSE008516R0001) is a precision analog input module for the ABB AC 800M and Advant OCS platforms. It is designed for applications requiring accurate measurement of standard process variables.

Request Quote
Category: SKU: ABB AI810 (3BSE008516R0001)

Description

ABB AI810 (3BSE008516R0001)

Technical Specifications:

  • Order Code: 3BSE008516R0001.
  • Channels: Multiple analog input channels (typically 8 or 16 depending on variant).
  • Signal Range: Configurable for standard current and voltage signals.
  • Accuracy: High-precision measurement with low temperature drift.

Functional Features:

  • Flexible Configuration: Software-selectable input ranges.
  • Diagnostic Capabilities: Wire-break and out-of-range detection.
  • High Reliability: Designed for continuous industrial duty.

Application Scenarios:

  • Process control in chemical and pharmaceutical industries.
  • Power plant auxiliary monitoring.
  • Water and wastewater treatment.

Material Composition & Structural Characteristics:

  • Construction: Industrial-grade PCB with conformal coating.
  • Terminals: Standard screw or spring-clamp terminals.

Working Principle:
Field signals are acquired, filtered, and converted to digital values. The module applies calibration and scaling factors before presenting data to the controller.

Installation Requirements:

  • Install on appropriate Advant/AC 800M terminal base.
  • Use shielded cabling for signal integrity.
  • Configure input parameters in Control Builder M.

Usage Precautions:

  • Do not exceed maximum input voltage/current ratings.
  • Verify terminal base compatibility.
  • Perform calibration checks periodically.
