Product Introduction:
The ABB CI858 is an EtherNet/IP communication adapter for the S800 I/O system. It provides native EtherNet/IP connectivity, allowing ABB distributed I/O to integrate directly into Rockwell Automation and other EtherNet/IP-based control networks.

Request Quote
Category: SKU: ABB CI858 3BSE018136R1

Description

ABB CI858 3BSE018136R1

Technical Specifications:

  • Protocol: EtherNet/IP (CIP).
  • Network Speed: 10/100 Mbps.
  • Order Code: 3BSE018136R1.

Functional Features:

  • Native CIP Support: Full compliance with EtherNet/IP specifications.
  • Integrated Switch: Supports linear and star topologies without external switches.
  • Web Configuration: Built-in HTTP server for easy IP setup and diagnostics.

Application Scenarios:

  • Integration with Allen-Bradley ControlLogix/CompactLogix PLCs.
  • High-speed distributed I/O in food & beverage and packaging industries.

Performance Parameters:

  • Data Refresh: Fast cyclic update rates.
  • Node Capacity: Supports multiple devices on the internal switch.

Material Composition & Structural Features:

  • Ports: Dual RJ45 with magnetic isolation.
  • Housing: Compact S800 adapter form factor.

Working Principle:
Encapsulates I/O data into CIP packets, communicating directly with EtherNet/IP scanners over standard TCP/IP networks.

Installation Requirements:

  • Configure IP address and subnet mask via web interface or rotary switches.
  • Use CAT5e shielded industrial Ethernet cables.

Usage Precautions:

  • Ensure no IP address conflicts exist on the network.
  • Verify EDS file configuration in the PLC programming software.
