ABB CI858K01 3BSE018135R10
Technical Specifications:
- Protocol: PROFIBUS DP-V1.
- System: ABB S800 I/O and AC 800M.
- Baud Rate: Up to 12 Mbit/s.
- Physical Interface: 9-pin D-sub connector.
- Redundancy: Supports redundant PROFIBUS networks.
Functional Features:
- DP-V1 Master/Slave: Flexible configuration for various network topologies.
- Redundant PROFIBUS: Dual PROFIBUS interfaces for high availability.
- Advanced Diagnostics: Comprehensive network and device diagnostics.
Application Scenarios:
- Connecting PROFIBUS drives, motors, and field devices.
- Redundant PROFIBUS networks in critical process areas.
- Distributed I/O stations with PROFIBUS integration.
Performance Parameters:
- High-Speed DP-V1: Fast cyclic and acyclic data exchange.
- Redundant Switchover: Seamless failover in redundant PROFIBUS configurations.
Material Composition & Structural Characteristics:
- Form Factor: S800 I/O communication unit.
- Connectors: Dual 9-pin D-sub PROFIBUS connectors.
Working Principle:
The CI858K01 manages the PROFIBUS DP-V1 network, cyclically exchanging I/O data with configured slaves. In redundant configurations, it monitors both PROFIBUS links and automatically switches to the backup link if a failure is detected, ensuring continuous communication with field devices.
Installation Requirements:
- PROFIBUS Wiring: Use certified PROFIBUS cables with proper termination and grounding.
- Redundant Configuration: Connect both PROFIBUS interfaces to separate network segments.
- GSD Files: Import correct GSD files for all connected devices.
Usage Precautions:
- Termination: Ensure proper termination on both PROFIBUS networks.
- Addressing: Verify unique addresses for all devices on both networks.
