Description
ABB DSTA-121A 57120001
Technical Specifications:
- Product Type: I/O Module Connection Unit.
- Part Number: 57120001-NY.
- System Compatibility: ABB S100 I/O, Advant OCS, MasterPiece 200.
- Dimensions: Net depth 363 mm, net height 60 mm, net width 110 mm.
- Weight: 0.365 kg.
Functional Features:
- Analog Signal Routing: Specifically engineered to handle sensitive analog signals with minimal interference.
- Modular Integration: Seamlessly integrates with the S100 I/O termination units to expand system capacity.
- Regulatory Compliance: Exempted from the scope of 2011/65/EU (RoHS) as provided in Article 2(4)(c), (e), (f), and (j) for industrial control systems.
Application Scenarios:
- Process control systems requiring precise analog signal acquisition and output.
- Integration of field transmitters and actuators into the ABB Advant Master Process Control System.
Performance Parameters:
- Signal Integrity: Optimized layout to reduce noise coupling in analog circuits.
- Reliability: Designed for continuous operation in harsh industrial environments.
Material Composition & Structural Features:
- Housing: Durable industrial-grade enclosure.
- Connectors: High-density terminal blocks designed for secure field wiring connections.
Working Principle:
Provides a structured wiring path that maps the internal pins of the S100 analog I/O modules to external field cables, ensuring correct signal routing and electrical isolation.
Installation Requirements:
- Mount securely onto the designated S100 I/O baseplate or DIN rail.
- Ensure proper strain relief on field cables to prevent terminal damage.
Usage Precautions:
- Handle with standard electrostatic discharge (ESD) precautions.
- Verify wire gauges and torque specifications during field wiring to ensure solid connections.
