ABB HBFFAEAGNBA1BAA11G

ABB HBFFAEAGNBA1BAA11G

Product Brief (generic SD I/O module interpretation):​ This is a plug-in I/O module for ABB Symphony Plus / INFI 90 Evolution systems, residing on an SD termination unit (HTU/HBX) and communicating via HN800 bus. It digitizes field analog signals or drives field actuators per its encoded type. The module is hot-swappable, galvanically isolated, and provides per-channel/open-circuit/short-circuit diagnostics to the controller.

Request Quote
Category: SKU: ABB HBFFAEAGNBA1BAA11G

Description

ABB HBFFAEAGNBA1BAA11G

  • How to Decode (example patterns):
    • HDI…​ → Digital Input 24 V DC, 16 ch, sinking/sourcing
    • HDO…​ → Digital Output 24 V DC, 16 ch, 0.5 A sourcing, short-circuit protected
    • HAI…​ → Analog Input 4–20 mA / TC / RTD (HAI805 = 8 ch 4–20 mA HART)
    • HAO…​ → Analog Output 4–20 mA 8 ch
    • HRT…​ → HART option enabled
  • Typical Technical Specs (if Digital Output example — HDO):
    • 16 ch × 24 V DC sourcing, 0.5 A/ch, group isolated, OSP configurable, short-circuit protected
    • HN800 bus interface, hot-swap, LED diagnostics
  • Application / Structure / Working Principle / Installation / Precautions:
    • Install on correct SD termination unit (HBX01 / HTU…) — keying prevents mismating
    • In Control Builder / Symphony Plus Engineering Workbench, select the decoded I/O type (HDI/HDO/HAI/HAO) from the I/O catalog — the long code auto-populates
    • Wire per termination unit diagram; verify loop supply polarity for analog, sourcing vs sinking for digital
    • Precaution:​ The encoded part number must match the ordered function — if unsure, decode via ABB I/O selection tool or cross-reference the 18-char code in the Symphony Plus I/O manual(2VAA001983 etc.)
