ABB HIEE200038R0001
ABB HIEE200038R0001 - Image 2

ABB HIEE200038R0001

Product Overview:
The ABB HIEE200038R0001 is a multifunctional industrial automation module designed for integration into various industrial control systems. It primarily functions to convert digital signals into relay contact actions, enabling precise external device control. The module provides stable power supply and signal conversion, ensuring the efficient operation of complex industrial facilities.

Request Quote
Category: SKU: ABB HIEE200038R0001

Description

ABB HIEE200038R0001

Technical Specifications:

  • Input Voltage: 4-20 mA.
  • Output Voltage: 24 VDC.
  • Maximum Output Current: 10A.
  • Communication Interface: Modbus TCP.
  • Protection Level: IP20.
  • Dimensions: 8 x 8 x 15 cm (approximate PCB size 150mm x 100mm).
  • Weight: 2.5 kg.

Functional Features:

  • High Precision: Features ±0.1% accuracy for both input and output signals.
  • Signal Conversion: Converts standard 4-20 mA signals into reliable relay outputs.
  • Seamless Integration: Designed to integrate flawlessly with PLCs (Programmable Logic Controllers) and other DCS systems.
  • Status Indication: Equipped with LED indicators for real-time operational monitoring.

Application Scenarios:

  • Chemical plants, power stations, and manufacturing factories.
  • Industrial automation and control systems requiring stable power and signal conversion.

Performance Parameters:

  • Stability: Low noise and high stability for demanding industrial applications.
  • Temperature Range: Operates reliably in extreme environments from -40°C to +85°C.

Material Composition & Structural Characteristics:

  • Housing Material: Durable metal enclosure.
  • Internal Design: Compact green or blue PCB design.
  • Mounting Options: Supports both DIN rail and panel mounting.
  • Wiring Interface: Features screw terminals and quick-connect wiring options.

Working Principle:
The module receives analog current signals (4-20 mA) from field sensors or controllers. The internal circuitry processes this signal and drives the internal relay mechanism. When the threshold is met, the relay contacts close or open, thereby switching the 24 VDC output to control external actuators, valves, or motors.

Installation Requirements:

  • Mount securely on a standard DIN rail or flat panel using appropriate hardware.
  • Ensure adequate ventilation to maintain operating temperatures below the 85°C maximum limit.
  • Connect Modbus TCP cables using shielded twisted-pair wiring to prevent communication interference.

Usage Precautions:

  • Verify the 24 VDC power supply polarity before energizing the module.
  • Do not exceed the 10A maximum output current rating to prevent relay contact welding.
  • Ensure proper grounding of the shielded communication cables to maintain Modbus TCP signal integrity.
