Product Overview:
The ABB KX8974c V24 is a versatile 24V control relay or interface module used in ABB automation systems. It provides electrical isolation and signal amplification between low-voltage PLC outputs and higher-power field devices, ensuring reliable switching and control.

Request Quote
Category: SKU: ABB KX8974c V24

Description

ABB KX8974c V24

Technical Specifications:

  • Coil Voltage: 24V DC.
  • Contact Configuration: Typically SPDT or DPDT (Form C).
  • Contact Rating: Rated for industrial control loads (e.g., 2A-6A at 250VAC).
  • Version: V24 indicates 24V DC coil operation.

Functional Features:

  • Electrical Isolation: Complete galvanic isolation between coil and contacts.
  • Signal Amplification: Allows low-current PLC outputs to switch high-power loads.
  • Status Indication: Mechanical flag or LED to indicate relay energization.
  • Surge Protection: Built-in flyback diodes or RC snubbers to protect PLC outputs.

Application Scenarios:

  • Switching solenoid valves, contactors, and motor starters.
  • Alarm annunciation and indicator lamp control.
  • Interposing relay for PLC output protection.

Performance Parameters:

  • Mechanical Life: High-cycle rated for millions of operations.
  • Electrical Life: Silver-alloy contacts for long life under inductive loads.
  • Response Time: Fast pickup and release times for precise control.

Material Composition & Structural Characteristics:

  • Contacts: Silver-cadmium oxide or silver-tin oxide for arc resistance.
  • Coil: Epoxy-encapsulated copper winding for vibration resistance.
  • Housing: Flame-retardant thermoplastic enclosure.

Working Principle:
When 24V DC is applied to the coil, it generates a magnetic field that pulls the armature, closing or opening the contact points. This switches the external load circuit. When the coil is de-energized, a spring returns the contacts to their resting state.

Installation Requirements:

  • Mounting: Securely mount on DIN rail or plug into designated socket base.
  • Wiring: Use appropriate wire gauge for the load current.
  • Protection: Verify built-in suppression is present; add external snubbers for highly inductive loads if necessary.

Usage Precautions:

  • Load Matching: Never exceed the contact voltage and current ratings.
  • Inductive Loads: Always use suppression devices to prevent contact welding and PLC output damage.
  • Inspection: Replace the module if contacts are welded, pitted, or the coil is open.
