Product Brief:​

The NTAI05 is the S100-bus analog input module​ functionally equivalent to the S800 AI835but for the S100 I/O system. It:

  • Plugs into an S100 termination unit (TA563 with TA567 analog terminal block) on DIN rail
  • Connects to S100 bus (via SPCJ4D34 cluster processor or directly to CI520A if S100 is remote I/O to AC 800M)
  • Each channel independently software-configured (TC type, RTD, V, mA) — mixed on same module (within CJC grouping: ch 1–4 share CJC sensor; ch 5–8 share second CJC)
Request Quote
Category: SKU: ABB NTAI05

Description

ABB NTAI05

  • Technical Specifications (typical NTAI05):
    • Channels: 8 differential (2 groups ×4)
    • Input Types: TC (J,K,T,E,N,R,S,B — linearized per IEC 60584), RTD (Pt100 α=3850/3926, Ni100 — 2/3/4-wire), ±10 V, 0–10 V, ±20 mA, 0–20 mA, 4–20 mA (250 Ω int. shunt — jumper on TA567)
    • Resolution: 16 bit (0.0015 % FS)
    • Accuracy: ±0.1 % Rd (V/mA); ±0.5 °C + TC class (TC); ±0.2 °C + sensor (RTD)
    • Isolation: 500 V AC ch-group ↔ S100 bus; 50 V AC between groups
    • Power: From S100 bus (5 V logic + 24 V UP via SPU01)
    • Indicators: Run (green), Err (red), Warning (amber), Ch Active LEDs (some versions)
    • Mounting: On S100 TU (TA563/TA566) — DIN 35 mm
    • Operating Temp.: 0 °C to +55 °C
    • Certifications: CE, UL, cUL, marine
  • Functional Features / Application / Material / Structure / Working Principle / Installation / Precautions:​

    Same principles as S800 AI835 described earlier — key differences:

    • Uses TA567 analog terminal block​ (screw terminals + shunt jumpers mA/V) — jumper set to “mA” for 4–20 mA, “V” for voltage
    • CJC sensor located on TA567 (not on module) — ensure TA567 is correct type (with CJC) for TC apps
    • Configured in Advant Engineering Workbench (for AC 450) or Control Builder M (for AC 800M + CI520A) — assign module type NTAI05 → set ch params → download
    • Wire & commission per AI835 guidelines (TC polarity, RTD 3-wire, mA shunt jumper, open-sensor burnout dir)
    • Precaution (S100 specific):​ S100 bus must be terminated (95 Ω at last node via NPCT-01C or SPU01 jumper). Verify SPU01 (NPOW-62C) sized for ∑ module currents. TA567 CJC version must match — if using TC, order TA567 with CJC (not plain V/mA TB).
