Product Overview:
The ABB PFEA112-20 (Order Code: 3BSE050091R20) is an advanced tension transducer belonging to the PFEA112 series. This series often features enhanced processing capabilities, additional communication options, or improved dynamic response compared to the base PFEA111 models, catering to more complex web handling requirements.

Request Quote
Category: SKU: ABB PFEA112-20 3BSE050091R20

Description

ABB PFEA112-20 3BSE050091R20

Technical Specifications:

  • Series: PFEA112 Advanced Tension Transducer.
  • Order Code: 3BSE050091R20.
  • Input: Dual-channel or high-precision single-channel load cell input.
  • Output: Isolated 4-20 mA / 0-10 VDC.
  • Power: 24 VDC nominal supply.

Functional Features:

  • Advanced Algorithms: Enhanced filtering and dynamic compensation for high-speed applications.
  • Diagnostics: Comprehensive fault detection including load cell wire break, short circuit, and overload.
  • User Interface: Intuitive front-panel display and keypad for local configuration and monitoring.
  • Memory: Stores calibration data and configuration parameters internally.

Application Scenarios:

  • High-performance converting and slitting lines.
  • Precision coating and laminating processes.
  • Battery electrode manufacturing.
  • Advanced textile and non-woven production.

Performance Parameters:

  • Dynamic Response: Optimized for applications with rapid tension setpoint changes.
  • Accuracy: Tight tolerance band for premium product manufacturing.
  • Stability: Long-term stability reduces the frequency of recalibration.

Material Composition & Structural Characteristics:

  • Enclosure: High-quality industrial housing with excellent EMC shielding.
  • PCB: Surface-mount technology (SMT) for reliability and compactness.
  • Display: High-contrast LED or LCD display for easy reading in various lighting conditions.

Working Principle:
Building upon the PFEA111 architecture, the PFEA112-20 utilizes faster digital signal processing to handle dynamic tension variations. It continuously monitors the load cell signal, applies real-time compensation for machine dynamics, and outputs a highly responsive tension signal. The local display allows operators to view real-time tension and diagnostic status without connecting a laptop.

Installation Requirements:

  • Configuration: Use the front panel or software to configure load cell parameters, output scaling, and filter settings.
  • Wiring: Ensure proper shielding and grounding of all signal and power cables.
  • Calibration: Perform a full calibration using certified test weights after installation.

Usage Precautions:

  • Parameter Backup: Always back up configuration parameters before replacing a unit or updating firmware.
  • Environmental Limits: Avoid installation in areas with excessive vibration or corrosive atmospheres.
  • Safety: Follow lockout/tagout procedures when working on associated machinery.
