Product Introduction:
The ABB PP835 is a robust, high-performance operator panel belonging to the ABB Panel 800 series. It serves as a highly reliable Human-Machine Interface (HMI) designed to facilitate seamless interaction between operators and industrial automation systems, such as ABB AC 800M controllers and Modbus devices.

Request Quote
Category: SKU: ABB PP835

Description

ABB PP835

Technical Specifications:

  • Power Requirements: 24 V DC nominal (tolerant to typical shop floor supply variations).
  • Communication Interfaces: 10/100 Ethernet, RS-232, and RS-485 serial ports.
  • Display Technology: High-resolution TFT/LED display with vector-based graphics.
  • Protection Rating: IP65 at the front panel when properly mounted.

Functional Features:

  • Versatile Connectivity: Supports multiple industrial protocols including Modbus TCP/RTU and native ABB PLC drivers.
  • Data Management: Features a USB host port for convenient backup, restore, and transfer of recipes, logs, and firmware without requiring a laptop.
  • Rugged Front Panel: Designed to withstand harsh environments, offering excellent resistance to dust and wash-down conditions.

Application Scenarios:
Widely deployed in power generation auxiliaries, water/wastewater stations, HVAC systems, pulp and paper mills, chemical processing, and food and beverage packaging lines.

Performance Parameters:

  • Operating Temperature: Typically 0°C to +50°C (non-condensing).
  • Project Migration: Fully supports project conversion and updates via the Panel Builder 800 environment.

Material Composition:
Features a rugged, die-cast powder-coated aluminum enclosure for the rear housing, combined with a durable, chemically resistant polyester fiber touchscreen overlay.

Structural Features:
Compact panel-mounting design utilizing a sealing gasket and clamping system. It includes a multi-color status LED on the front panel and standard D-sub and RJ45 communication ports on the rear.

Working Principle:
Acts as an intelligent terminal that communicates with the underlying PLC via Ethernet or serial buses. It renders graphical user interfaces locally, processes touch inputs, and translates operator actions into control commands sent back to the automation system.

Installation Requirements:
Must be mounted in a rigid, clean panel surface using the supplied gasket. Torque the clamps evenly to ensure a uniform IP65 seal. Provide adequate ventilation behind the panel to prevent thermal hotspots.

Usage Precautions:
Use shielded CAT5e/6 cables for Ethernet connections in high-EMI areas. Clean the touchscreen regularly with a lint-free cloth and isopropyl alcohol. Ensure the 24 V DC power supply is regulated and properly grounded to extend the panel’s lifespan.
