Description
ABB TC512V1 3BSE018059R1
Technical Specifications:
- Order Code: 3BSE018059R1.
- Function: Analog Signal Interface.
- System: ABB Industrial I/O.
Functional Features:
- Signal Shielding: Integrated shielding to protect low-level analog signals from EMI.
- Filter Circuits: Built-in hardware filtering for stable measurements.
- Ground Isolation: Galvanic isolation to prevent ground loops.
Application Scenarios:
Process measurement including temperature, pressure, and flow transmitters in noisy industrial environments.
Performance Parameters:
- Signal-to-Noise Ratio: High SNR for accurate process data.
- Input Impedance: Optimized for standard 4-20mA and 0-10V signals.
Material Composition:
High-dielectric PCB with precision analog components.
Structural Features:
Dedicated shield termination points and color-coded analog terminals.
Working Principle:
Conditions and routes analog signals from field transmitters to the input module while actively rejecting electromagnetic interference.
Installation Requirements:
Use shielded twisted-pair cables. Connect cable shields to the designated terminal base shield points.
Usage Precautions:
Never route analog cables parallel to high-voltage power cables. Verify signal grounding scheme.
