Description
Bently 3300/16-12-01-01-00-02-00
Technical Specifications
- Product Series: 3300 Vibration Monitoring System
- Part Number: 3300/16-12-01-01-00-02-00
- Channel Configuration: Dual Channel
- Input Type: Proximity Probe (Eddy Current)
- Customization: Factory-configured variant
Functional Features
- Modified Configuration: Incorporates specific factory settings to address unique monitoring or protection requirements.
- Dual Channel Processing: Maintains the core dual-channel functionality while offering specialized output or alarm behavior.
- Reliable Operation: Built on the proven 3300/16 platform, ensuring high reliability and performance.
Application Scenarios
Used in applications where standard module behavior requires modification, such as integration with legacy control systems or specialized machinery protection schemes.
Performance Parameters
- Measurement Range: 0 to 500 µm (0 to 20 mils) Peak-to-Peak (unless otherwise specified)
- Frequency Response: 10 Hz to 10 kHz
- Accuracy: ±1% of full scale
- Output Signal: Modified per “-02-00” configuration
Material Composition
Standard industrial-grade materials with robust enclosure and high-quality internal components, consistent with the 3300 series reputation for durability.
Structural Characteristics
Standard 3300 rack module form factor. The specific suffix may affect internal component layout but maintains external compatibility with standard racks.
Working Principle
Operates on the fundamental eddy current demodulation principle, with potential modifications to signal processing or output generation as defined by the specific part number.
Installation Requirements
Compatible with all 3300 series racks. Ensure proper grounding and follow wiring diagrams specific to this configured variant.
Usage Notes
Consult the specific technical documentation for this part number to understand the exact nature of the “-02-00” configuration. Standard setup procedures may not apply.
