Description
Bently 3300/20-12-01-01-00-00-00
Technical Specifications
- Product Series: 3300 Vibration Monitoring System
- Part Number: 3300/20-12-01-01-00-00-00
- Channel Configuration: Dual Channel
- Input Type: Proximity Probe (Eddy Current)
- Customization Level: Factory-configured variant
Functional Features
- Customized Configuration: Tailored factory settings to match specific machinery protection philosophies or legacy system integrations.
- Precision Axial Measurement: Maintains high-accuracy axial displacement measurement with specialized signal conditioning.
- Reliable Signal Processing: Ensures accurate translation of mechanical axial movement into electrical signals for control systems.
Application Scenarios
Designed for specialized rotating equipment or unique industrial environments where standard thrust position monitoring parameters do not apply, often found in custom-built compressor skids or specialized power generation units.
Performance Parameters
- Measurement Range: Configurable based on specific application requirements
- Frequency Response: 0 Hz (DC) to 5 Hz
- Accuracy: ±1% of full scale
- Output Signal: Analog and relay outputs as per custom specification
Material Composition
Industrial-grade steel enclosure with conformal-coated internal circuit boards to protect against moisture, dust, and corrosive gases.
Structural Characteristics
Standard 3300 rack form factor with front-panel indicators and test points. The specific suffix indicates unique internal component layouts or factory-set parameters.
Working Principle
Operates on the same eddy current demodulation principle as standard 3300 modules, converting probe impedance changes into precise axial position readings.
Installation Requirements
Requires a compatible 3300 series rack. Installation must be performed by qualified personnel familiar with custom-configured Bently Nevada equipment.
Usage Notes
Due to its customized nature, technical documentation and calibration procedures may differ from standard modules. Always refer to the specific OEM manual or factory data sheet for this exact part number.
