Description
Bently 330130-080-01-00
Technical Specifications
- Cable Type: 3300 XL 8mm Extension Cable
- Length: 8.0 meters (26.2 feet)
- Construction: Armored
- Connectors: Standard ClickLoc
Functional Features
- Mechanical Protection: The armored sheath shields the internal signal conductors from crushing, abrasion, and rodent damage.
- Signal Integrity: Precision coaxial geometry maintains consistent impedance and prevents signal loss over long distances.
- EMI Shielding: Provides excellent protection against electromagnetic interference in electrically noisy environments.
Application Scenarios
Essential for installations where the Proximitor transducer must be located far from the probe, such as in outdoor environments or areas with high ambient temperatures.
Performance Parameters
- Capacitance: Matched to 3300 XL system requirements
- Operating Temperature: -51°C to +177°C (standard armored)
- Impedance: 50 Ohms nominal
Material Composition
Inner PTFE dielectric, braided copper shield, and outer stainless steel or galvanized steel armor jacket.
Structural Characteristics
Flexible yet rugged coaxial cable with ClickLoc connectors on both ends for seamless connection between the probe and transducer.
Working Principle
Serves as a passive transmission line, carrying the high-frequency RF signal from the probe to the transducer without altering the signal characteristics.
Installation Requirements
Route the cable away from high-voltage power lines to prevent induced noise. Secure the cable with appropriate clamps to prevent vibration-induced fatigue.
Usage Precautions
Do not kink or bend the cable beyond its minimum bend radius. Inspect the armor regularly for signs of corrosion or physical damage.
