Description
Bently 330173-00-04-10-02-00
Technical Specifications
- Product Series: 3300 5mm Proximity Probe
- Part Number: 330173-00-04-10-02-00
- Probe Diameter: 5mm
- Case Length: 50mm
- Total Cable Length: 1.0 meter (3.3 feet)
- Connector Type: Miniature coaxial ClickLoc connector
- Agency Approval: Not required
Functional Features
- Non-Contact Measurement: Measures the gap between the probe tip and a conductive target surface without physical contact.
- Compact Design: The 5mm diameter allows installation in tight spaces where larger probes cannot fit.
- High Sensitivity: Provides precise measurement of radial vibration, axial displacement, and shaft position.
- System Compatibility: Compatible with 3300 XL 5mm extension cables and Proximitor sensors.
- Wide Frequency Response: Supports dynamic vibration measurement.
Application Scenarios
Used in conjunction with 3300 5mm extension cables and Proximitor sensors to form a complete proximity transducer system. Common applications include small turbines, compressors, pumps, fans, and gearboxes in power generation, petrochemical, refining, and steel industries. The compact 5mm diameter is particularly suitable for installations with limited mounting space or small shaft diameters.
Performance Parameters
- Probe Diameter: 5mm
- Case Length: 50mm
- Total Cable Length: 1.0 meter
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Linear Range: 2mm
