Description
Bently 330604-00-13-10-02-00
Technical Specifications
| Parameter Category | Specific Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Family | 3300 XL 11mm Proximity Transducer System |
| Thread Specification | 3/4-14 NPT (National Pipe Thread) |
| Unthreaded Length | 00 = 0.0 mm (no unthreaded section) |
| Overall Case Length | 13 = 13.0 mm |
| Total Cable Length | 10 = 1.0 meter (3.3 feet) |
| Cable Option | 02 = Non-armored (standard) |
| Agency Approval | 00 = No agency approval required |
| Probe Diameter | 11.0 mm |
| Linear Range | 4.0 mm (160 mils) |
| Sensitivity | 3.94 V/mm (100 mV/mil) with system |
| Target Material | Calibrated for AISI 4140 steel |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel |
| Operating Temperature (Probe) | -34°C to +177°C (-30°F to +350°F) |
| Storage Temperature | -51°C to +260°C (-60°F to +500°F) |
| Pressure Sealing | Viton O-ring standard |
| DC Resistance | 7.59 ± 0.50 ohms (for 1.0m cable) |
| Typical Capacitance | 85 pF/meter |
| Weight | Approximately 0.2 kg |
Key Features
- Larger 11mm Diameter: Provides 4.0 mm (160 mils) linear range, double that of the 8mm system
- 3/4-14 NPT Thread: Large pipe thread for heavy-duty industrial mounting
- 13mm Case Length: Compact case with full thread to tip design
- TipLoc and CableLoc Technology: Strong mechanical bonds
- ClickLoc Connector: Reliable connection
- Full System Interchangeability: Interchangeable within 3300 XL 11mm system
- API 670 Compliance: Complete system meets API 670 Standard requirements
Application Scenarios
- Large steam turbine shaft monitoring: Measures shaft vibration and position with greater linear range
- Generator air gap monitoring: Monitors larger air gaps in large generators
- Large compressor thrust position: Measures axial displacement with greater range
- Hydro turbine wicket gate position: Monitors large wicket gate openings
- Large pump impeller position: Measures impeller axial position in large pumps
- Rolling mill roll position: Monitors roll position and vibration in metal rolling mills
- Large fan shaft monitoring: Measures vibration in large industrial fans
