Description
Bently 3500/05-01-01-00
Technical Specifications
- Frame Type: 19-inch EIA Standard Rack (Full Size)
- Module Capacity: 14 available module slots
- Mounting Option: Panel Mount
- Revision Level: Base configuration
Functional Features
- Panel Mount Design: Optimized for direct panel mounting with integrated clamping hardware.
- Full Capacity: Supports up to 14 monitor modules plus required power and interface modules.
- Hot-Swap Capability: All modules support hot insertion and removal for zero-downtime maintenance.
- Backplane Integrity: Verified backplane continuity and signal integrity for reliable system operation.
Application Scenarios
Standard deployment in industrial control panels and machinery protection cabinets across power, oil & gas, and manufacturing sectors.
Performance Parameters
- Environmental Rating: Suitable for indoor industrial environments
- Thermal Management: Designed for natural convection cooling with adequate clearance
- Mechanical Strength: Rated for continuous industrial vibration exposure
Material Composition
Heavy-gauge steel construction with corrosion-resistant coating and precision-machined card guides for reliable module seating.
Structural Characteristics
19-inch rack form factor with front-access module slots, rear I/O connector access, and integrated panel mounting clamps. Includes grounding provisions and cable tie-down points.
Working Principle
Serves as the mechanical and electrical backbone of the 3500 system, providing power distribution and data communication through the integrated backplane to all installed modules.
Installation Requirements
Secure to panel using provided clamping hardware. Maintain minimum 2-inch clearance above and below for ventilation. Connect instrument ground per API 670 requirements.
Usage Precautions
Verify panel cutout dimensions match frame specifications. Do not install modules in power supply or interface slots. Ensure proper torque on mounting hardware to prevent frame distortion.
